Compact Disc Harrow

Name: Compact Disc Harrow
Brand: SABIN ENTERPRISES
Price: 1700 USD
Availability: InStock

Price 1700 USD ($)/ Number

Get a Price/Quote

MOQ : 1 Number

Compact Disc Harrow Specification

Usage & Applications
Agricultural

Features
working width of cassava harvester is 1600mm

Tool Type
Harvester

Product Type
Harrow

General Use
Agricultural

Capacity
0.33-0.53ha/h Kg

Weight (kg)
1260 Kilograms (kg)

Type
Disc Harrow

Drive Type
Belt Drive

Power
50 - 90 HP Horsepower (HP)

Power Source
other

Transmission Type
Belt

Engine Type
Other

Fuel Tank Capacity
NA Kilogram(Kg)

Engine Oil Capacity
NA Kilogram(Kg)

Start Method
Electric Start

Disc Diameter
560, 610, 660 Millimeter (mm)

Tilling Scope
NA

Machine Speed
2.1 - 6.7 Km/hr

Production Output
0.33-0.53ha/h Product/Hour

Dimension (L*W*H)
1950 x 1920 x 1350 Millimeter (mm)

Color
Red

Warranty
NA

Compact Disc Harrow Trade Information

Minimum Order Quantity
1 Number

FOB Port
Any Port in India

Supply Ability
5 Per Month

Delivery Time
3 Week

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
Export worthy packaging

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

About Compact Disc Harrow

Features:

* It can be used in both forms i.e. mounted as well as trailed.

* High quality boron steel disc with 48 - 52 HRC hardness

*Tillage depth of the harrow is 150 - 200 mm

* Easily transportable - as it gets easily attached and mounted

* Adjustable gang axles angle up to 46 Celsius

* High quality bearings and hubs ensure smooth operation and put minimum load on the tractor

* High quality seals prevent the entry of mud and water into the bearings and hubs

Description	16 Disc	18 Disc	20 Disc	22 Disc
Type of Mounting	Three point Hinged Linkage (Cat II)
Disc Dia (mm) (Optional)	560, 610, 660
Disc Type	Front: Notched, Rear: Plain
Frame	100 x 100
Disc Spacing (mm)	230
Maximum Depth (mm)	150 - 200 (Depends on soil moisture and field conditions)
Gang Shaft	32 sq. Bar
Width of Cut (mm) (Adjustable)	1900	2100	2220	2450
Bearings Hub	6	8	8	8
Suitable HP Range	50 - 60	60 - 70		80 - 90

Engineered for Performance and Reliability

Designed for agricultural professionals, the Compact Disc Harrow combines dependable belt drive transmission with a powerful electric start. It supports machine speeds between 2.1 and 6.7 Km/hr and accommodates varying tractor horsepower (50-90 HP), ensuring compatibility and reliability for a range of farming needs.

Versatile Applications in Agriculture

This disc harrow is an indispensable tool for modern farms, especially in tasks like soil tilling and harvesting root crops such as cassava. Its generous working width of 1600mm and large disc diameters (560, 610, 660 mm) guarantee fast, consistent field coverage, saving time and increasing productivity.

Built for Stability and Efficiency

Weighing 1260 kg, the harrow is perfectly balanced for stability in diverse field conditions. Its durable construction and efficient belt transmission guarantee long-lasting performance, cementing its role as a crucial investment for large-scale agricultural operations.

FAQ's of Compact Disc Harrow:

Q: How does the Compact Disc Harrow operate in the field?

A: The Compact Disc Harrow utilizes a belt drive transmission system and electric start for ease of use. It attaches to tractors with 50-90 HP power and is capable of achieving working speeds between 2.1 to 6.7 Km/hr, making it efficient for soil preparation and crop harvesting tasks.

Q: What benefits does the Compact Disc Harrow offer for agricultural usage?

A: This disc harrow provides a substantial working width of 1600 mm with sizable discs, enabling high productivity (0.33-0.53 ha/h). Its sturdy build and efficient drive ensure consistent soil breaking and support diverse farming activities including cassava harvesting.

Q: When is it most effective to use this disc harrow?

A: The harrow is particularly effective during pre-planting season for tillage and residue management, as well as during harvest time for root crops like cassava. Its robust design supports regular seasonal tasks on medium to large farms.

Q: Where is the Compact Disc Harrow manufactured and available for export?

A: This machine is produced in India and is available for export by the manufacturer, making it accessible to agricultural operations worldwide seeking reliable tillage solutions.

Q: What is the process of starting and operating this disc harrow?

A: The harrow is started electrically, which simplifies preparation before use. After coupling to a compatible tractor, operators engage the belt drive system for straightforward and efficient operation in the field.

Q: What types of power sources are compatible with this disc harrow?

A: Tractors with horsepower ranging from 50 to 90 HP are suitable for this harrow, supporting the unit's size and required working speed for effective soil and crop management.

Q: How does the disc diameter influence the function of the harrow?

A: With available disc diameters of 560, 610, and 660 mm, the harrow can handle a range of soil types and field conditions. Larger discs ensure deeper penetration and better mixing of the soil, improving overall tillage results.
